Bioreactors & Fermenters
ANTICO BioCore™ is designed for biological processes such as fermentation and cell culture. The working principle involves maintaining controlled environmental conditions for biological growth and reactions. The system includes a vessel, agitator, aeration system, sensors, and control unit. It regulates parameters such as temperature, pH, and dissolved oxygen. The reactor supports sterile operation and contamination control.
It is used for microbial and cell-based production processes. The system enables efficient mass transfer and nutrient distribution. It is widely used in pharmaceuticals, biotechnology, and food industries. It supports scalable biological production. ANTICO BioCore™ ensures reliable and controlled bioprocessing.
- Capacity 1 L – 5,000+ L
- MOC (Vessel) Borosilicate Glass 3.3 (lab) / SS316L (pilot …
- Design Type Stirred Tank Bioreactor (STR)
- Operation Mode Batch / Fed-batch / Continuous
- Design Pressure Vacuum to +2 barg
- Design Temperature 5°C to 150°C
Key Features
-
Sterile operation
Sterile operation
-
Precise oxygen transfer
Precise oxygen transfer
-
pH control
pH control
-
Nutrient dosing
Nutrient dosing
-
Automated monitoring
Automated monitoring
-
Engineered for Reliable Operation
Built for demanding chemical and pharmaceutical process environments.
System Components
Modular assemblies engineered for reliable integration, service access, and scale-up from laboratory to pilot plant operation.
Applications
- Biotechnology
- Pharmaceuticals
- Biofuels
- Food fermentation
- Enzyme manufacturing
- Probiotics production
- Oil & gas processing
- Water treatment
Technical Specifications
| Parameter | Specification |
|---|---|
| Capacity | 1 L – 5,000+ L |
| MOC (Vessel) | Borosilicate Glass 3.3 (lab) / SS316L (pilot & production) |
| Design Type | Stirred Tank Bioreactor (STR) |
| Operation Mode | Batch / Fed-batch / Continuous |
| Design Pressure | Vacuum to +2 barg |
| Design Temperature | 5°C to 150°C |
| Sterilization | Autoclavable (lab) / SIP (steam-in-place) |
| Agitator Type | Rushton / Marine / Pitch Blade |
| Speed Range | 50 – 1000 RPM (VFD controlled) |
| Aeration System | Sparger (Ring / Sintered) |
| Gas Control | Air / O₂ / CO₂ / N₂ with MFCs (optional) pH Control |
| Inline probe with acid/base dosing | DO Control |
| Optical / Polarographic DO sensor | Temperature Control |
| Jacket / Heating Blanket | Foam Control |
| Antifoam dosing / Foam sensor (optional) | Instrumentation pH, DO, Temp, Pressure, Agitation |
| Automation | PLC / SCADA with recipe & data logging |
| Compliance | GMP / 21 CFR Part 11 (optional) |
| Applications | Cell Culture, Fermentation, Enzymes, Biologics |
Related Products
FAQ
What capacity range is available for Bioreactor / Fermenter?
We offer project-specific sizing from laboratory benchtop scale through pilot and production volumes. Contact our engineers with your batch size and process requirements for a tailored recommendation.
Can this unit be integrated with existing plant automation?
Yes. All systems support standard instrumentation signals and can interface with DCS, PLC, or standalone controllers. Custom I/O and recipe control packages are available.
What material options are available?
Borosilicate glass, glass-lined steel, stainless steel, and specialty alloys including Hastelloy can be specified based on your process chemistry, temperature, and pressure requirements.
Do you provide installation and commissioning?
Global Lindus provides on-site installation supervision, commissioning, operator training, and optional IQ/OQ documentation for regulated industries.
What is the typical delivery lead time?
Standard configurations ship in 4–8 weeks. Custom skid assemblies and large production units may require 12–16 weeks depending on scope and material availability.
